Install and Upgrade Internal Modules and Field Replaceable Units
1 0
Micro USB 2.0
1 1
RSSI 0
• Yellow: Very bad
• Green: Very bad
1 2
RSSI 1
• Yellow: Bad signal,
• Green: Bad signal, 4G
1 3
RSSI 2
• Yellow: Good signal,
• Green: Good signal,
1 4
RSSI 3
• Yellow: Best signal,
• Green: Best signal, 4G
This section describes how to insert a Micro-SIM card into an LTE pluggable module.
To insert the Micro-SIM cards into an LTE Pluggable module:
Note
Ensure to use the correct tool for removing the Micro-SIM door.
1. Place the pluggable module on its bottom side, remove the SIM door screw, use a #1 Philips screw driver
for removing the screws, and then carefully remove the Micro-SIM cover from the pluggable module.
Caution
2. Slot 1 and slot 0 are the Micro-SIM slots. (see figure 5, step 2).
3. Install SIM 0 and SIM 1 in their respective slots. SIM 0 or SIM 1 is marked on the pluggable interface
module above the Micro-SIM cover. The SIM icons show the correct orientation required to install the
SIM into each respective connector (SIM connectors are a push-push type).
To install, insert the SIM card in the connector until you feel it click, then let go and the SIM is locked
to the connector. To remove the SIM card, depress the SIM in the connector slot again until you feel the
signal, 3G
signal, 4G
3G
3G
4G
3G
Do not touch any part of the exposed PCB circuit area when the Micro-SIM cover is removed.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
Install a Pluggable Interface Module on a C1101-4P
83
