Overview of Cisco 1000 Series Integrated Services Routers
Figure 25: LED Indicators - Bezel Side
1
3
5
7
Figure 26: LED Indicators - I/O Side
1
3
5
7
9
Status
WLAN
LTE RSSI/mode
Cisco logo
GE WAN ports: 0-7 (0, 2, 4, 6 at the top and
1, 3, 5, 7 at the bottom)
GE1 LED
USB LED
USB console
CD LED
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
2 VPN
4 GPS
6 LTE data/SIM
2 PoE LED
4 GE0 LED
6 RJ-45 console LED
8 Micro USB console LED
10 DATA LED
LED Indicators
