Cisco C1131X-8PLTEPW Series Hardware Installation Manual page 40

Rack Mount
Note
Depending on the model, the available options for mounting a Cisco 1000 Series Integrated Services Router
are:
Table 9: Models and Mounting Options
Model
C111x and C1111X
C1101-4P
C1101-4PLTEPWx
C1109-2PLTExx
C1121-4Px
C1126(X)-8PLTEP
C1128(X)-8PLTEP
C1131(X)-8PLTEPWx
C1131(X)-8PWx
C111x
C1121/C1161
If you choose to setup the router on a desktop, you can place the router on a desktop, bench top or on a shelf.
Rack Mount
Secure the rack mounting brackets on the sides of the chassis. You must first secure rack mounting brackets
on the chassis before you set up the chassis on the rack.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
34
You can install external modules before or after mounting a router. However, if you choose to install the
external modules after mounting the router on the rack or wall, ensure that you have optimal access to the
back/front panel of the router.
For information on modules and Field Replaceable Units (FRUs), see the
FRUs section.
Mounting Options
Desktop,
using-Din-Rail
Desktop,
Desktop,
Desktop,
Desktop,
Desktop,
Desktop,
Desktop,
Desktop,
