ADLINK Technology I-Pi SMARC User Manual page 33

I-Pi-SMARC User's Guide
5.12 GPIO
Name Pin Description
#
GPIO0 / P108 General purpose I/O pin 0.
CAM0_PWR#
GPIO1 / P109 General purpose I/O pin 1.
CAM1_PWR#
GPIO2 / P110 General purpose I/O pin 2.
CAM0_RST#
GPIO3 / P111 General purpose I/O pin 3.
CAM1_RST#
GPIO4 / P112 General purpose I/O pin 4.
HDA_RST#
GPIO5 / P113 General purpose I/O pin 5.
PWM_OUT
GPIO6 P114 General purpose I/O pin 6.
GPIO7 P115 General purpose I/O pin 7.
GPIO8 P116 General purpose I/O pin
8.
GPIO9 P117 General purpose I/O pin 9.
GPIO10 P118 General purpose I/O pin
10.
GPIO11 P119 General purpose I/O pin
11.
GPIO12 S142 General purpose I/O pin
12
GPIO13 S123 General purpose I/O pin
13
Note: All GPIO are on RPI header.
Page 26
I/O I/O Power PU / PD
Type Level Domain
I/O 1.8V Runtime PU 470K on the
CMOS Module.
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
I/O 1.8V Runtime PU 470K on the
CMOS Module
copyright © 2024 ADLINK Technology Inc.
SGET SMARC Rev 2.1
Comments
Default use is GPIO0, alternative use is Camera 0
Power Enable - active low, through DTS
Default use is is GPIO1 alternative use is Camera
1 Power Enable - active low, through DTS
Default use is GPIO2, alternative use is Camera 0
Reset - active low, through DTS
Default use is GPIO3, alternative use is Camera 1
Reset - active low, through DTS
