5.8.2 2nd LAN
Name Pin # Description
GBE1_MDI0+ S17 Gigabit Ethernet Controller 1: Media Dependent
GBE1_MDI0- S18 Interface Differential Pairs 0, 1, 2, 3. The MDI can
GBE1_MDI1+ S20 operate in 1000, 100, and 10Mbit/sec modes. Some
GBE1_MDI1- S21 pairs are unused in some modes according to the
GBE1_MDI2+ S23 following:
GBE1_MDI2- S24
GBE1_MDI3+ S26 MDI[0]+/-
GBE1_MDI3- S27 MDI[1]+/-
MDI[2]+/-
MDI[3]+/-
GBE1_LINK100# S19 Link Speed Indication LED for GBE 1 100Mbps
GBE1_LINK1000# S22 Link Speed Indication LED for GBE 1 1000Mbps
GBE1_LINK_ACT# S31 Link / Activity Indication LED Driven low on Link (10, 100
or 1000 mbps) Blinks on Activity
GBE1_CTREF S28 Center-Tap reference voltage for Carrier board Ethernet
magnetic `(if required by the Module GBE PHY)`
GBE1_SDP P5 IEEE 1588 Trigger Signal. For hardware implementation
of PTP (precision time protocol)
Note: The number of functional LAN ports is dependent on the module used.
Page 21
1000 100 10
B1_DA+/- TX+/- TX+/-
B1_DB+/- RX+/- RX+/-
B1_DC+/-
B1_DD+/-
copyright © 2024 ADLINK Technology Inc.
I/O I/O Power
Type Level Domain
GBE MDI Runtime
O OD 3.3V Runtime
CMOS
O OD 3.3V Runtime
CMOS
O OD 3.3V Runtime
CMOS
Analog 0 to 3.3V Runtime
max
IO 3.3V Runtime
CMOS
SGET SMARC Rev 2.1
PU / Comments
PD
Twisted pair signals for external
transformer.
Shall be able to sink 24mA or more Carrier
LED current
Shall be able to sink 24mA or more Carrier
LED current
Shall be able to sink 24mA or more Carrier
LED current
