I-Pi-SMARC User's Guide
USB3_SSTX+ S62 Transmit signal differential pairs for
USB3_SSTX- S63 SuperSpeed on port 3
USB3_EN_OC# P74 USB over-current sense for port 3
USB3_VBUS_DET S37 USB port 3 host power detection,
when this port is used as a device.
USB3_OTG_ID S104 Input pin to announce OTG device
insertion on USB 3.0 port
USB4+ S35 USB differential data pairs for port 4
USB4- S36
USB4_EN_OC# P76 USB over-current sense for port 4
Note: USB0 is directly connected to the SoC, USB1/2/3/4 might come over a USB hub on the SMARC module.
Page 18
O USB SS Standby
USB SS
I/O OD 3.3Vsb / Standby
CMOS 3.3V
I USB VBUS 5V Standby
USB VBUS 5V
I 3.3Vsb / Standby
CMOS 3.3V
I/O USB Standby
USB
I/O OD 3.3Vsb / 3.3V Standby
CMOS
copyright © 2024 ADLINK Technology Inc.
Coupling caps for TX pairs are on the Module
PU 10k Pulled low by Module OD driver to disable USB0 power. Pulled
low by Carrier OD driver to indicate over-current situation.
PU 10k Pulled low by Module OD driver to disable USB0 power. Pulled
low by Carrier OD driver to indicate over-current situation.
SGET SMARC Rev 2.1
