When installed, the pin next to the wire spool hub in the wire feeder must align and go into the hole in the spool or
spool adapter.
"Installing and changing wire (X5 WF HD300)" on page 75
1.5.2 Wire feed mechanism
X5 Wire Feeder HD300 wire feed mechanism:
1.
Drive rolls and drive roll mounting caps
2.
Middle guide tube locking clip
3.
Middle guide tube
© Kemppi
25
X5 FastMig
Operating manual - EN
1920960 / 2440
