Argon + 18-25% CO2
CO2
* Depending on the gas nozzle size.
** Depending on the gas nozzle size and welding current.
Adjusting gas guard (optional)
The sensitivity level of the optional (with X5 Wire Feeder HD300 only) gas guard can be adjusted as follows.
1. Open the interconnection cable cabinet.
2. Turn the gas guard adjustment screw with a flathead screwdriver to adjust the sensitivity in the desired direction
(+/-).
3. Test that the gas guard works correctly with the new setting.
The gas guard can be turned on and off in the control panel settings: "Manual control panel: Settings" on page 93 and
"AP/APC control panel: Device settings" on page 114.
© Kemppi
- 10...25 l/min
- 10...25 l/min
