Changing memory channel
Turn the right control knob to highlight the desired memory channel. The highlighted memory channel is automatically
activated.
Managing memory channels
The memory channels are managed through the Actions menu.
1. Enter the actions menu by pressing the right control knob.
2. Turn the control knob to highlight the desired action.
3. Select the action by pressing the right control knob.
4. Make further selections as required.
Available actions are:
• Save changes: Save changes to the currently selected channel
• Save to: Save the current settings to another channel
• Rename: Rename the channel
• Delete: Delete the currently selected channel
• Link to WPS: Link the currently selected channel to a weld pass on a digital welding procedure specification
(dWPS) document. (Optional. The WPS feature is available with X5 Wire Feeder APC.)
• Create channel: Create a new channel based on the welding program(s)
>> MIG only: Welding programs can be filtered by base material, wire material, wire diameter, shielding gas and process.
For more information, refer to "AP/APC control panel: Applying welding programs" on page 117.
• Create from programs: Create new channels based on all of the unused welding programs available (in MIG mode
only)
• Delete all: Delete all channels.
The skewed channel number in the top left corner of the channel selection indicates that the set welding parameters are
different from the ones currently saved on the active memory channel:
Tip: Changed welding parameters can be quickly saved onto the active memory channel by keeping the
Memory channels button pressed for approx. 2 seconds. This works in any view.

3.3.4 APC control panel: WPS view

The use of digital WPS (Welding Procedure Specification, dWPS) and WeldEye cloud service require X5 Wire Feeder 300 APC
and a valid Kemppi WeldEye subscription with the Welding Procedures module. The X5 equipment includes a link to a free
trial registration – featuring also a free trial option for WeldEye ArcVision. For more information on WeldEye, refer to
com or contact your Kemppi representative.
To take the digital WPS feature in use, the equipment must be connected to the internet via the built-in wireless con-
nection (WLAN). Refer to "Wireless connection (WLAN)" on page 126 for instructions.
Trial registration
The X5 FastMig with X5 Wire Feeder 300 APC comes preinstalled with a trial license for the WeldEye Welding Procedures
module. The trial license can be activated by following these steps:
