2. Select a weld pass on the dWPS by turning the right control knob and enter the actions menu by pressing the right
control knob button.
>> The linked memory channel set as default is emphasized (in brighter blue) for each weld pass.
3. If a memory channel has already been linked to the weld pass, you can activate the selected weld pass and the
default memory channel by selecting 'Activate'.
4. If a memory channel has not been linked to the weld pass previously, you can link the weld pass to an existing
memory channel ('Select linked channel').
A memory channel can also be linked to a weld pass on a dWPS through the Memory channels view by selecting
'Link to WPS' in the memory channel's actions menu.
Once a weld pass on a dWPS is activated, the default memory channel linked to it is automatically selected. This is indic-
ated also in the home view and on screen during welding.
The welding parameters are still manually adjustable, but the adjustment ranges defined on the active WPS are indic-
ated on the screen (1). If you adjust the welding parameters outside the WPS adjustment range, the control panel shows
a warning (2) on the screen:
