5. Coolant circulation warning
>> The LED is green when the coolant circulation is working normally.
>> The LED is red when there is a problem in the coolant circulation.
If the circulation of the coolant liquid is obstructed, a thermal cutoff switches the welding system off. Check and fix
the error before using the welding system again.
Rear:
1.

Power switch

2. Voltage sensing cable connector (Pulse+ power sources only)
3. Control cable connector
4. Control cable connector
5. Mains cable
6. Welding current cable connector, plus (+) connector
7. Earth return cable connector, minus (-) connector
8. Rear locking interface
>> For locking on top of the cooling unit or on the cart.
