Appendix | Sensor Values, Data Format, Conversion
A 4.14 ODC2700
RS422 The data are configured or selected via ASCII commands or via the web interface.
Baud rate 921600 Baud ex factory
Ex factory, the controller outputs the measurements in the Strip edge preset to the web diagram, i.e., output must be redirected to
the RS422 interface.
The ODC2700 supplies 3 bytes per value at the output. These bytes are coded by the IF2035-PROFINET into 4 bytes, see
The linearized measuring values can be converted in µm using the following formula:
d
OUT
x [mm] =
100000
Fig. 33 Calculation of edge position from the digital value, ODC2700
Please refer to the operating instructions for the laser micrometer optoCONTROL 2700 for more information. The current version is
available at:
https://www.micro-epsilon.com/download-file/manuals/man--optoCONTROL-2700--en.pdf
IF2035-PROFINET
st
x = Measuring value (1 edge starting with SMR) in mm
d = digital output value
OUT
Chap. 5.3.
