Appendix | Sensor Values, Data Format, Conversion
A 4.13 ODC2520
RS422 The data are configured or selected via ASCII commands or via the web interface.
Baud rate 115200 Baud ex factory
Ex factory, the controller outputs the measurements in the Edge light-dark measuring program to the web diagram, i.e., output
must be redirected to the RS422 interface.
The ODC2520 supplies 3 bytes per value at the output. These bytes are coded by the IF2035-PROFINET into 4 bytes, see
The linearized measuring values can be converted in µm using the following formula:
x [µm] = d - 131000
OUT
Fig. 32 Calculation of edge position from the digital value, ODC2520
Please refer to the operating instructions for the laser micrometer optoCONTROL 2520 for more information. The current version is
available at:
https://www.micro-epsilon.de/download/manuals/man--optoCONTROL-2520--en.pdf
IF2035-PROFINET
x = Measuring value (edge position, difference, center axis) in µm
d = digital output value; d
OUT
≥ 262072 are error values
OUT
Chap. 5.3.
