Functional Principle, Technical Data

2. Functional Principle, Technical Data
2.1

Functional Principle

The IF2035-PROFINET interface module is used to convert the internal Micro-Epsilon sensor protocol
(RS485 or RS422) to PROFINET IO.
Features:
- Synchronization output, LED status display
- PROFINET interface
- Housing for top-hat rail
Depending on the interface used, one sensor (with RS422) or several sensors (with RS485) can be connected via one module.
2.2

Technical Data

Model
1
Speed
Supply voltage
Power consumption
Digital interface
Digital output
Connection
Mounting
Temperature range
Operation
1) corresponds to the minimum cycle time
IF2035-PROFINET
IF2035-EtherCAT
0.25 ms
RS422, RS485
(with Micro-Epsilon specific
data protocol),
baud rate 9600 baud ...
4 MBaud, EtherCAT
Digital output synchronization (TTL, HTL) for RS422 sensors
2 x RJ45 for fieldbus, 4 screw terminals for sensor connection and power supply
Storage
IF2035-PROFINET
1 ms, 0.5 ms (IRT)
9 ... 36 VDC
approx. 1.25 W with 24 VDC (without sensor)
RS422, RS485
(with Micro-Epsilon specific
data protocol),
baud rate 9600 baud ...
4 MBaud, PROFINET
DIN rail 35 mm
-20 ... 70°C
0 ... 50 °C
IF2035-EIP
1 ms
RS422, RS485
(with Micro-Epsilon specific
data protocol),
baud rate 9600 baud ...
4 MBaud, EtherNet/IP
