Object Directory - MICRO-EPSILON IF2035-PROFINET Operating Instructions Manual

Initial Operation
5.4

Object Directory

Index Subindex Data type
0x2000 0 Uint8
0x2001 0 Uint8[32]
0x2010 0 Uint32[64] R
0x2020 0 Uint32
0x2021 0 Uint8
0x2023 0 Uint8
0x2024 0 Uint8
0x2025 0 Uint8
0x2026 0 Uint8
0x2027 0 Uint8
IF2035-PROFINET
Name
RW select sensor
R sensor addresses
device error log
RW baud rate
RW minimum cycle time
RW serial sensor interface
W clear device config
W clear sensor config
W reset device
enable/disable
RW
HTTL Sync
RS485 RS422 Description
Address of currently selected sensor
Shows address list of available sensors
Reads out the last 32 error codes with time stamp
IF2035 baud rate
Minimum time for one communication cycle in ms,
cycle time = 0: use estimated time
0: RS485,
1: Reserved,
2: ASCII + RS422
3: 32 Bit ASCII + RS422
One byte deletes settings from flash, settings are
included in RAM until restart
One byte deletes settings from flash, settings are
included in RAM until restart
One byte performs reset
0: Disable HTTL synchronization
1: Enable HTTL synchronization
Page 20
