Installation and Assembly
i
Ensure careful handling during installation and operation.
.904 max
4.236 max
22.6
107
.878 min
4.197 min
TS35
Top-hat rail
Dimensions in mm
113.7 (4.476)
(inches, rounded off)
Pin Assignment
Terminal 2
Terminal 2
Terminal 4
V
M1M2
T
T
R
R
V+ Supply voltage
Ground for supply voltage
M1 Multifunction input 1
M2 Multifunction input 2
Terminal 1 connections daisy-chained
Terminal 1
V+ Supply voltage
Ground for supply voltage
M1 Multifunction input 1
M2 Multifunction input 2
Terminal 2 connections daisy-chained
1) If the distance between IF2035-PROFINET and the
V
M1M2
A B S S
sensor/controller is long, a separate supply for the
Terminal 1
Terminal
sensor/controller may be advisable.
Supply Voltage
The supply voltage is daisy-chained from the supply
port (terminal 1) to the sensor port (terminal 2), i.e., the
supply voltage must match that of the sensor. Positive
voltage must be between 9 V and 36 V.
Connect the inputs V+ and
on terminal 1 to a
voltage supply. Maximum cable length 3 m.
MICRO-EPSILON recommends using the optionally
available power supply PS2020.
N
L
230 VAC
Cable Termination at Interface
i
Ensure correct cable termination for an RS485 bus or RS422 bus! The IF2035-PROFINET
works as a master for both interfaces; internally, a 120 Ohm terminating resistor has already
been permanently incorporated. The IF2035-PROFINET should be at the bus start.
A
120
120
120
Ohm
Ohm
Ohm
B
120
Ohm
IF2035
Slave n
IF2035
Slave n-1
RS485
RS422
n = max. 16 Slaves
Terminal 4
1
T+ RS422 Tx+
T-
RS422 Tx-
R+ RS422 Rx+
R-
RS422 Rx-
Ground
2
e.g., for RS422 shield connection
Terminal 3
1
A
RS485 A
B
RS485 B
S+ Synchronization output +
S-
Synchronization output -
2
Ground
e.g., for RS485 shield connection
2) Internally connected to supply ground
Connection Options
RS485
RS422
Sensor/
Cable
Cable
Controller
SCAC3/6
Direct
DT6120
PCx/8-M12
SC2471-x/RS422/OE
INC5701
PC7400-6/4
Direct or PCF1420-x/I/U
MSC7xxx
PC5/5-IWT
PC1700-x/OE
DTD
PC1900-x/OE
PE
PC2300-x/OE
PC2250-x
SC2471-x/RS422/OE
CAB-M12-8P-St-ge
PC/SC2520-x
RX+
120
The length of the cable between IF2035-PROFINET and sensor/controller is 10 m at most. Because of
Ohm
RX -
the PCx/8-M12 cable, the sensor supply for INC5701 sensors is possible only via the IF2035-PROF-
INET.
TX -
Standard Cabeling
120
Ohm
TX+
During cabling, channel 0 of the IO controller is connected to the input port of the first IO device
(slave device). The output port of the first slave device is connected to the input port of the next
Slave 1
slave device, etc. The output port of the last slave device and channel 1 of the master device remain
unused.
Scanner
Adapter 1
Adapter 2
You achieve greater failsafe network performance if you implement an additional redundant connec-
tion (MRP = Media Redundancy Protocol) between the output port of the last slave device and chan-
nel 1 of the IO controller. IF2030 can participate in an MRP ring as a client; however, it cannot manage
the ring. To achieve ring functionality, all participants must be configured as ring participants.
Your local contact: www.micro-epsilon.com/contact/worldwide/
Sensor/
Controller
C-Box Analog
IFD242x, IFD246x
ILD1x20
ILD1750
ILD19x0
ILD2300
ILR2250
IMS54xx, IMS56xx
MFA-7/14/21/28
ODC2520
Intended Use
The IF2035-PROFINET interface module is designed for use in industrial and laboratory applications.
It is used to convert the internal MICRO-EPSILON sensor protocol (RS485, RS422) to Profinet.
The interface module must only be operated within the limits specified in the technical data.
The interface module must be used in such a way that no persons are endangered or machines and
other material goods are damaged in the event of malfunction or total failure of the sensor/controller.
Take additional precautions for safety and damage prevention in case of safety-related applications.
Warnings
Connect the power supply and the display/output device according to the safety regulations for
electrical equipment.
> Risk of injury
> Damage to or destruction of the interface module
The supply voltage must not exceed the specified limits.
Redundancy
> Damage to or destruction of the interface module
Avoid shocks and impacts to the interface module.
Adapter n
> Damage to or destruction of the interface module
Proper Environment
Protection class:
IP 20
Operating temperature: 0 ... +50 °C (+32 ... 122 °F)
Storage temperature:
-20 ... +70 °C (-4 ... +158 °F)
Humidity:
5 - 95% (non-condensing)
MICRO-EPSILON MESSTECHNIK GmbH & Co. KG
Ambient pressure:
Atmospheric pressure
Koenigbacher Str. 15 • 94496 Ortenburg
e-mail info@micro-epsilon.com
www.micro-epsilon.com
X9771467-A012103MSC
Assembly Instructions
IF2035-PROFINET
