Module Parameters - MICRO-EPSILON IF2035-PROFINET Operating Instructions Manual

Initial Operation
5.7.4

Module Parameters

You can specify basic settings using the TIA portal inter-
face. Proceed as follows to configure the IF2035-PROF-
INET based on a few basic parameters.
In the Hardware catalog, select the Basic
settings output module and place it in the next
free slot in the Device overview.
The input module must be located before the basic
settings module.
Double-click the module in the Device over-
view. In the Inspection window, navigate to
the Properties > General > Component param-
eters tab.
IF2035-PROFINET
Fig. 18 Basic settings module in the hardware catalog
Page 37
