Appendix | Sensor Values, Data Format, Conversion
A 4.3 ACS7000
RS422 Measuring rate 250 Hz ex factory, all color values and color distances. Up to 32 output values can be transmitted
at the same time.
Baud rate 115200 b/s
ACS7000 supplies 3 bytes per value at the output. These bytes are coded by the IF2035-PROFINET into 4 bytes, see
Group Name
Framerate
Shutter
Status
TempDetector
TempLightSrc
Red
Green
LightSensor
Blue
Brightness
Counter
Status
Timestamp
XYZ
RGB
LAB
LUV
Color LCH (L/C)
LCH (H)
LAB99
LCH99 (L/C)
LCH99 (H)
IF2035-PROFINET
Raw
Index
Min Max
1 2500 250000
2 2500 250000
3 -1024 1023
4 -1024 1023
5 0 65535
6 0 65535
7 0 65535
8 0 65535
9 0 262143
10 0 262143
11-13 0 131072
14-16 0 131072
17-19 -131072 131071
20-22 -131072 131071
23-24 -131072 131071
25 0 131071
26-28 -131072 131071
29-30 -131072 131071
31 0 184320
Scaled
Min Max Formula
20,00 2000,00 10^6/(x*12,5*2^4)*1000
20,00 2000,00 x*12,5*2^4)/10^9
-256,00 255,75 x/4
-256,00 255,75 x/4
0,00 100,00 x/65536*100
0,00 100,00 x/65536*100
0,00 100,00 x/65536*100
0,00 100,00 x/65536*100
0 262143 x
0,00 67,11 x*256/100000
0,00 256,00 x/512
0,00 256,00 x/512
-256,00 256,00 x/512
-256,00 256,00 x/512
-256,00 256,00 x/512
0,00 256,00 x/512
-256,00 256,00 x/512
-256,00 256,00 x/512
0,00 360,00 x/512
Chap. 5.3.
Unit
Hz
µs
°C
°C
%
%
%
%
-
s
-
-
-
-
-
°
-
-
°
