Appendix | Sensor Values, Data Format, Conversion
A 4.9

ILD2300

RS422 The data are configured or selected via ASCII commands or via the web interface.
Baud rate
691200 baud ex factory
i
The sensor can continue to supply measurements to the RS422 output even while the sensor is communicating.
The digital measurements are output at the sensor as unsigned digital values (raw values). 16 Bit per value are transmitted. The sen-
sors supply 3 bytes per value at the output. These bytes are coded by the IF2035-PROFINET into 4 bytes, see
The linearized measuring values can be converted in µm using the following formula:
Value Variables
Distance
x = digital value
MR = measuring range [mm] {10/25/50/100/200/500}
d = distance [mm]
Fig. 28 Calculation of distance value from the digital value, ILD2300
Please refer to the operating instructions for the laser-optical displacement sensors optoNCDT 2300 for more information, especially
about possible output values. The current version is available at:
https://www.micro-epsilon.de/download/manuals/man--optoNCDT-2300--en.pdf
1) When delivered, ILD2300 is set for 691.2 kBaud. Increase the baud rate to 921.6 kBaud in the sensor.
IF2035-PROFINET
1
Value range
[0; <643] SMR reserve
[643; 64877] Measuring range
[>64877; 65520] EMR reserve
[-0,01MR; 1,01MR]
Formula
1 102
d [mm] = x - 1
100 65520
Chap. 5.3.
* MR [mm]
Page 56
