Appendix | Sensor Values, Data Format, Conversion
Group
Name
Status
Error
1_1/2/3
...
16_1/2/3
Distance
Min_1/2/3
DetectedID
MinDistID
Fig. 23 Overview of output data via RS422
Please refer to the operating instructions for the color measuring system colorCONTROL ACS7000 for more information, especially
about possible output values. The current version is available at:
https://www.micro-epsilon.com/download/manuals/man--colorCONTROL-ACS7000--en.pdf
IF2035-PROFINET
Raw
Index
Min
Max
32
0
262143
33-35
NA
-
36-77
78-80
-
81-83
-131072
131071
84
0
16
85
0
16
Scaled
Min
Max
Formula
0
262143
x
-256,00
256,00
x/512
0
16
-
0
16
-
Unit
-
-
-
-
Page 50
