Initial Operation
Specify the required settings, e.g., baud rate, sensor
interface. Enable the settings by using the parameter
Init-Config.
Detailed information about this process is available in the
Baud rate and Interface section, see
Save your changes by clicking the Save
button (at top left on the function bar).
Now you can load the settings into the CPU.
Select your S7 device in the Working window if this
has not been done already, and click the Load to
device symbol button on the Function bar.
Reboot the IF2035-PROFINET to have the changes
take effect!
i
This step is necessary because of the selected/used mechanism for establishing a GUI to parameterize the IF2035-PROFINET; it
prevents the configuration from being sent repeatedly to the CPU as programs are run.
IF2035-PROFINET
Chap. 5.2.
