Initial Operation
5.7.3

Executing Function Component

To create a global data component, se-
lect your CPU's Program components
folder in the Project navigation
and then click Add new block.
In the next dialog window, select the
option Data block and change the
name, if necessary. Select Global DB
for the type. Enable the check mark Add
new and open, unless this has already
been done automatically. Confirm the
selection with OK.
The data component is automatically displayed.
Now create the necessary variables, depending on the function component.
The starting value is the value used when the data component is loaded into the CPU's memory.
Next, click the Save project button (top left on the function bar).
