Installation and Assembly

4. Installation and Assembly
i
Ensure careful handling during installation and operation.
4.1

Installation of the Interface Module

+0.35
22.6
-0.3
(.89)
TS35
Top-hat rail
Fig. 1 IF2035-PROFINET dimensional drawing, dimensions in mm (inches)
IF2035-PROFINET
+0.6
107
-0.4
(4.21)
113.7 (4.48)
