Outlet State/Control State Descriptions
The following table shows the differences between outlet state and control state
The outlet state is the current operating state of the outlet.
•
The control state is the last user-issued control action on the outlet.
•
Outlet State Control State
On On
Off Off
Off Pend On
Off Reboot
On Idle On
On Idle Off
On Wake On
Off Wake Off
On/Wait Off
Off/Wait On
On/Error (varies)
Off/Error (varies)
Off/Fuse On
On/Fuse On
No Comm (varies)
Using the Web Interface
Description
Outlet is on.
Outlet is off.
Outlet is off and about to turn on in response to a sequence timer.
Outlet is off and a Reboot action has been initiated.
A restart has occurred – last control state has been maintained.
A restart has occurred – last control state has been maintained.
A power-loss has occurred – wakeup state has been applied.
A power-loss has occurred – wakeup state has been applied.
Outlet state in transition – re-query of outlet status required.
Outlet state in transition – re-query of outlet status required.
Error state – outlet should be off but current is sensed at the outlet.
Error state – outlet should be on but no current is sensed at the outlet.
Outlet should be on but a blown fuse has been detected.
Outlet should be on but a blown fuse has been detected downstream
Communication to the outlet has been lost – control state will be
applied when communication is re-established.
