Warning
The operational safety of the cabinet, particularly the personnel and product
protection, are guaranteed only if all safety functions of the cabinet have been tested
and approved.
Caution
Labconco will not warrant the operational safety if the cabinet is operated without the
required installation tests, or if these tests and are not performed by adequately
trained personnel.
Caution
The initial operation with subsequent installation test does not include any
decontamination measures. The working chamber and any accessories required
must be disinfected and cleaned in accordance with the hygiene guidelines set forth
for the desired application.
6

Operating the ReVo and ReVo Pro cabinets

All functions are controlled via the control panel shown below and by an electronic microprocessor
bases control system.
The control panel contains 6 buttons with LED for operating the basic functions in the cabinet, a text
display, that will show current running conditions and error messages and 5 buttons for navigational
purposes.
Button 1 with green LED light to select the fan ON/OFF at normal velocity. The green light
•
indicates that the fan is running at normal velocity, and that conditions are safe.
Button 2 with blue LED to select the fan ON/OFF at reduced velocity. Can be adjusted to any
•
level desired for individual requirements (See Service menu).
Button 3 with red light to silence the acoustic alarm.
•
Button 4 with blue light for normal light ON/OFF.
•
Control
buttons
Display
ENTER
24
Navigation
buttons
