There must be at least 100 mm clearance on the rear and non-utility side of the cabinet.
•
• For sides with external utility connections leave 150 mm clearance.
The location must be equipped with an appropriate ventilation system.
•
Room temperature between 10 °C and 35 °C.
•
• Relative humidity must not exceed 80%, up to 31 °C and is decreasing linearly to 50% at 40 °C.
The cabinets are for indoor use only.
•
Room ventilation should preferably be a ventilation system that complies with the national
requirements for the application.
The inlet air and exhaust air openings of the room ventilation must be located so that drafts do not
impair the function of the biological safety cabinet air system.
4.3

Transport

The cabinet can be moved through a standard 2000 mm x 800 mm door.
Transport of the ReVo / ReVo Pro can be carried out by lifting the cabinet using a forklift either
sideways under the support stand or directly under the trough. Furthermore, the cabinet can be
moved manually by using hooks in the dedicated holes in the support stand.
Caution
Whenever transportation of the cabinet is needed, precautions should be taken to
prevent it from overturning due to the high-located mass centre.
Caution
In order to prevent damage to the cabinet it must be handled as fragile goods.
Storage of the cabinet must be in an environment of maximum 80 % relative humidity and at
temperatures between 5 °C to 50 °C.
4.4

Exhaust connection for the ReVo and ReVo Pro cabinets

All Labconco ReVo safety cabinets are designed to operate in ducted exhaust applications. An anti-
blowback valve is mandatory (to be ordered separately) to prevent reverse airflow through the HEPA
filter. The cabinet is equipped with an interlock system that prevents the cabinet fans from operating
whenever the exhaust flow is insufficient. Labconco provides an optional potential free contact set
(normally open or normally closed) for easy on/off control of exhaust system dampers. The
associated control cable and control signal from the dampers to the cabinet must be provided and
specified in the lab requirements and will be connected by authorized personnel during installation
of the cabinet.
The signal and cable requirements are: 24 VAC/DC maximum 1A. Stranded cable gauge 2 x 0,25
mm with at least 2,5 m free length from access point behind or over the cabinet.
2
The exhaust system can remove at least the air volume specified by Labconco (typically 300 – 1000
m 3 /h) depending on the size of the cabinet. Labconco anti-blowback valves accommodate 200 mm
