Connecting Utilities To The Revo And Revo Pro Cabinets; Start-Up Of The Revo And Revo Pro Cabinets; Preparation - Labconco ReVo User Manual

4.8

Connecting utilities to the ReVo and ReVo Pro cabinets

If optional valves for utilities are delivered, make sure that local rules and regulations are complied
with during installation and use. It is generally recommended, to use an authorized technician for
this kind of work. Make sure that local rules and regulations regarding such installations are strictly
complied to.
Valves suited for any utility medium can be delivered. As default they are mounted in the holes in
the side windows. Optionally they can be mounted in the back wall.
5

Start-up of the ReVo and ReVo Pro cabinets

Caution
Correct assembly and installation is essential for proper start-up and operation of the
ReVo and ReVo Pro cabinets.
5.1

Preparation

Caution
The installations site for the unit must be draft-free and should be selected so that
frequent passing of people in front of the work opening is avoided.
1. The table tops of stainless steel are mounted over the trough.
2. Adjust the levelling screws to assure that the table top is in horizontal position and levelled.
3. Valves for gases or vacuum are installed in the side windows. A qualified technician must
make the connections for the supply.
4. For connection of the exhaust air to the exhaust air systems, special precautions which
must be discussed with the cabinet supplier must be taken.
When the cabinet has been installed:
1. Check that the front window is in the correct position, i.e. parallel to the front shield.
2. Never lift the front window manually - this will cause window to mall function.
3. Check that the window slides from top to bottom without any irregular sound.
4. If the window does not move when the UP or DOWN button is pressed, authorized service
personnel must be called to correct the fault.
5. Always keep hands and arms away from the working chamber when activating the front
window.
Product name
Valve, vacuum
Valve, other gasses
21
Catalogue No.
R3747500
Contact Labconco
