7.3.2. M-Bus modules
External M-Bus modules can be connected to the M3 thanks to the following screen.
It allows to mix 2 different probes on the same display with the multiplexer modules,
or to use input/output modules.
Multiplexer modules
The same process is made to connect all the multiplexer modules
Example M3 with MB-2S module (for Heidenhain probes) on the channel 2.
Page 48
M1 – M3 Display units
The probe
associated with
each channel can
be chosen here.
