Temperature tables
Measuring system Promass 83 (compact version)
at T = 50 °C
a
Promass F DN 8...40
Promass F DN 50
Promass F DN 80...150
Promass I DN 8...25, 15 FB
Promass I DN 40...50, 25 FB, 40 FB
Promass M DN 8...15
Promass M DN 25...40
Promass M DN 50
Promass M DN 80
Promass E DN 8...15
Promass E DN 25...50
Promass H DN 8
Promass H DN 15...50
at T = 60 °C
a
Promass A DN 1...4
Promass F DN 8...40
Promass F DN 50
Promass F DN 80...150
Promass I DN 8...25, 15 FB
Promass I DN 40...50, 25 FB, 40 FB
Promass M DN 8...15
Promass M DN 25...40
Promass M DN 50
Promass M DN 80
Promass E DN 8...50
Promass H DN 8
Promass H DN 15...50
The minimum medium temperature is –50 °C for Promass A/F/I/M/H.
The minimum medium temperature is –40 °C for Promass E.
*) The maximum permissible fluid temperatures apply only when the transmitter is
installed in such a way that it is not above the sensor and heat can be removed freely
by convection in all directions.
Sensor Promass (remote version)
at T = 60 °C
a
Promass A DN 1...4
Promass F DN 8...50
Promass F DN 80...150
DN 8...25
Promass I
Promass I DN 40...50, 25 FB, 40 FB
Promass M DN 8...15
Promass M DN 25...40
Promass M DN 50
Promass M DN 80
Promass E DN 8...50
Promass H DN 8
Promass H DN 15...50
The minimum medium temperature is –50 °C for Promass A/F/I/M/H.
The minimum medium temperature is –40 °C for Promass E.
PROline Promass 83 FOUNDATION Fieldbus
Max. medium temperature [°C] in
T6 T5 T4
55 95 130 150 (170*)
60 95 130 150 (170*)
60 75 110 150 (170*)
60 95 130
70 85 120
55 95 130
60 95 130
65 95 130
65 80 110
– 100 125
50 100 125
50 65 100
60 75 115
Max. medium temperature [°C] in
T6 T5 T4
60 95 130
55 95 100
60 95 100
60 75 100
60 95 130
70 85 120
55 95 100
60 95 100
65 95 100
65 80 100
– 100 125
50 65 100
60 75 115 160/180*
Max. medium temperature [°C] in
T6 T5 T4
60 95 130
55 95 130
60 75 110
60 95 130
70 85 120
55 95 130
60 95 130
65 95 130
65 80 110
– 100 125
50 65 100
60 75 115
T3 T2 T1
200* 200*
200* 200*
200* 200*
150 150 150
150 150 150
150 150 150
150 150 150
150 150 150
150 150 150
125 125 125
125 125 125
160 200 200
180 200 200
T3 T2 T1
150 200 200
100 100 100
100 100 100
100 100 100
150* 150* 150*
150* 150* 150*
100 100 100
100 100 100
100 100 100
100 100 100
125 125 125
160 200* 200*
200* 200*
T3 T2 T1
150 200 200
160 200 200
170 200 200
150 150 150
150 150 150
150 150 150
150 150 150
150 150 150
150 150 150
125 125 125
160 200 200
180 200 200
