iC7 Series Cooling Modules
Operating Guide
SUPPLY 400...690 VAC
±5 %, 50/60 Hz -XD0
L1
L1
L2
L2
L3
L3
PE
PE
Short-circuit
protected
Illustration 45: Wiring Diagram for Dual-pump iC7 Cooling Module with Auxiliary Transformer
Danfoss A/S © 2022.02
-QB0 -FC1
PE
-TA4
690
600
500
-FC4
460
400
01
-QA5.1 -FCX.1
-QA5.2 -FCX.2
-FCZ
-QAZ
Option +SKLH
Specifications
-TB7
L +
230
-
02 N -
-XD7.1
U
V
W
PE
-XD7.2
U
V
W
PE
-EBZ.1
L1
L2
L3
-EBZ.2
L1
L2
L3
AQ339830072437en-000202 / 172F0589 | 73
-P1
U1
M
V1
3
W1
PE
-P2
U1
M
V1
3
W1
PE
