7.5 Mains Connection Data
Table 14: Power Requirement of the Cooling Module
Characteristics of the cooling module
152 kW (380–690 VAC)
152 kW (400 VAC)
152 kW (690 VAC)
76 kW (380–690 VAC)
76 kW (400 VAC)
76 kW (690 VAC)
3~, 380–415 VAC or 660–690 VAC, 50/60 Hz
1
The power values are given at nominal voltage. With a liquid heater, power values vary with voltage.
2
Table 15: Short-circuit Current Rating
Characteristic
Short-circuit current rating with specified fuses
7.6 External Auxiliary Voltage Connection
Table 16: Cable Requirements for External Auxiliary Voltage Connection
Characteristic
Voltage
Power requirement
Cable recommendation
Strip length
Cable diameter
7.7 Routing Control Wires to the Control Compartment
It is possible to add signal and data connections to the control compartment. It is possible to connect, for example, a data bus cable,
a control cable, or an external leakage sensor.
Procedure
1. Use the recommended cable routing path.
2. In an enclosed or a standalone cooling module, route the control cables through the cable gland on the leakage plate in
the bottom of the cooling module.
3. In an enclosed cooling module, leave extra length for cables between the enclosure frame and door.
