3 Product Overview
3.1 Product Variants
The cooling module is available in different variants based on the protection rating, the cooling power, and the number of pumps.
The enclosed cooling module has the protection rating IP54, and the standalone cooling module has the protection rating IP23. The
available cooling power is 76 kW or 152 kW. The product can have 1 or 2 pumps.
3.2 Description of the Model Code
The model code defines the specifications of the product included in the delivery. It is shown on the package label. The model code
is made of standard codes and plus codes. Each part of the model code corresponds to the data in your order.
Example
The model code can have this format, for example:
iC7-60SLLQ40-0152E54F2+XXXX(+XXXX)
Table 3: Description of the Model Code
Code Description
iC7-60 Product group
SL
Product category
SL = system module, liquid-cooled
EL = enclosed drive, liquid-cooled
LQ
Product type
LQ = cooling module
40 Voltage rating
40 = 400 V AC (380–415 V AC ±5%) 50 Hz
46 = 460 V AC (440–480 V AC ±5%) 60 Hz
50 = 500 V AC (500–525 V AC ±5%) 50 Hz
60 = 600 V AC (575–600 V AC ±5%) 60 Hz
69 = 690 V AC (660–690 V AC ±5%) 50/60 Hz
-0152
Cooling power
-0076 = 76 kW
-0152 = 152 kW
E54 Protection rating
E23 = IP23 (standalone cooling module)
E54 = IP54 (enclosed cooling module)
F2 EMC category
F2 = C2 Industry environment
+SAP1 Cooling module configuration
+SAP1 = single-pump
+SAP2 = dual-pump
+XXXX Options
