Danfoss iC7 Series Operating Manual page 49

iC7 Series Cooling Modules
Operating Guide
1
2 3 4 5 6 7
Illustration 28: Control Compartment Door
1 Control panel (-PGA)
2 Pump 1 indication light (-PF2.1)
3 Pump 2 indication light (-PF2.2)
4 Cooling OK indication light (-PF3)
5 Fault indication light (-PF4)
Danfoss A/S © 2022.02
8
9
10
6 Alarm indication light (-PF5)
7 Reset button (-SF4)
8 Pump select switch (-SF2)
9 Run-Stop-Remote switch (-SF1)
10 Main switch (-QB0)
AQ339830072437en-000202 / 172F0589 | 49
Control Unit
