iC7 Series Cooling Modules
Operating Guide
11.1.3 Dimensions of the Single-pump Enclosed Cooling Module, Drive Circuit Pipes on the Left
475 (+SETL)
(18.70)
1844
(72.6)
1324
(52.12)
608.5
(23.96)
662
(26.06)
Illustration 33: Dimensions of the Single-pump Enclosed Cooling Module in mm (in), Drive Circuit Pipes on the Left
Danfoss A/S © 2022.02
95
(3.74)
212 (+SEDL)
(8.35)
335
Ø13
(13.19)
(0.51)
57 408
(2.24) (16.06)
335
(13.19)
36.5
(1.44)
535
(21.06)
36.5
(1.44)
407
(16.02)
610
(24.01)
36.5
(1.44)
2058
(81.02)
2038
1845 (+SETL)
(80.24)
(72.64)
2003
(78.86)
57
(23.96)
(2.24)
20
M12
