iC7 Series Cooling Modules
Operating Guide
Region Fuse type
North America Class CC, Time-Delay
7.2.4 Auxiliary Voltage Transformer (-TA4)
The cooling module is equipped with an auxiliary voltage transformer by default. The auxiliary voltage transformer supplies a
24 V DC power supply that distributes power to the control circuits. The auxiliary voltage transformer is protected by a circuit break-
er on the primary side.
If the cooling module is equipped with a cabinet heater, the auxiliary voltage must be provided externally.
Table 10: Specifications
Specification
Primary voltage
Secondary voltage
Frequency
Power
Maximum ambient temperature
Weight
7.2.5 24 V DC Power Supply (-TB7)
The 24 V DC power supply distributes power to the control electronics.
Table 11: Specifications
Specification
Input voltage range
Nominal output voltage
Nominal output current
Output power
7.2.6 Service Switch (-SF3)
SERVICE MODE
The service switch disables all the software protections of the cooling module. High temperature and pressure can cause serious
personal injury.
Running the cooling module in service mode can damage the equipment.
-
Only qualified personnel should use the service mode.
42 | Danfoss A/S © 2022.02
Current Catalog number
For 690 V AC supply, use 690 V AC rated fuse
15 A Mersen type: ATDR15
Eaton type: LP-CC-15
Value
400/460/500/600/690 V
230 V
47–63 Hz
50 VA
60 °C (140 °F)
1.7 kg (3.7 lb)
Value
100–240 V AC (-15%...+10%)
24 V DC
2.5 A
60 W
W A R N I N G
Electrical Installation
AQ339830072437en-000202 / 172F0589
