Danfoss iC7 Series Operating Manual page 72

iC7 Series Cooling Modules
Operating Guide
SUPPLY 400...690 VAC
±5 %, 50/60 Hz
-XD0
L1
L1
L2
L2
L3
L3
PE
PE
Short-circuit
protected
Illustration 44: Wiring Diagram for Single-pump iC7 Cooling Module with Auxiliary Transformer
72 | Danfoss A/S © 2022.02
-QB0 -FC1
PE
-TA4
690
600
500
-FC4
460
400
01
-QA5.1 -FCX.1
-FCZ
-QAZ
Option +SKLH
AQ339830072437en-000202 / 172F0589
Specifications
-TB7
230 L
N
02
-XD7.1 -P1
U
U1
V M
V1
3
W
W1
PE
PE
-EBZ.1
L1
L2
L3
-EBZ.2
L1
L2
L3
+
-
-
