iC7 Series Cooling Modules
Operating Guide
The attachment parts must not disturb the operation of the product or collide with the inlet and outlet piping.
2.
Attach the cooling module using the all the specified mounting holes.
See the location of the mounting holes in
Dimensions of the Dual-pump Standalone Cooling
The installation must be rigid. A good installation prevents the product from moving or being damaged by vibrations.
1
1
1
1
2
1
2
2
2
Illustration 8: Mounting Holes of the Standalone Cooling Module
1 Through hole, use an M8 screw
2 Through hole, use an M8 screw. Pre-attach-
ed screw and nut.
3. For the mounting holes that have a screw and a nut pre-attached, remove the nut. When attaching the cooling module,
replace the nut with a threaded support part (rivet nut).
The screw can be reused in the same mounting hole.
5.5 Installing the Enclosed Cooling Module
The enclosed cooling module is delivered installed in a Rittal VX25 cabinet (model code part E54).
Procedure
1. Attach the enclosed cooling module to the floor (4 fixing points) and to the wall (2 fixing points).
The floor and the wall must be rigid.
20 | Danfoss A/S © 2022.02
11.1.1 Dimensions of the Single-pump Standalone Cooling Module
Module.
3
3
3
3
3
3 Thread hole, M8
AQ339830072437en-000202 / 172F0589
Mechanical Installation
and 11.1.2
