Installation Guide
1

Product Introduction

1.1

Overview

Model
RG-NBS3100-
8GT2SFP-P-V2
Note

The eight Ethernet ports are PoE-capable, and comply with the IEEE 802.3af and 802.3at standards.
These ports support the Alternative A PoE power supply mode, which deliver power through pins 1/2 (+)
and pins 3/6 (-).

The SFP port is backward compatible with 100Base-FX.
1.2

Package Contents

Table 1-1 Package Contents
No. Item
1 RG-NBS3100-8GT2SFP-P-V2 Switch
2 Rubber Feet
3 Mounting Brackets
4 Quick Installation Guide
5 M3 x 6 mm Phillips Countersunk Screws
6 Management Software
7 Power Cord
8 Power Cord Retainer Clip
9 Yellow/Green Ground Wire
10/100/1000Base-T Ethernet
Port with Auto-Negotiation
8
1000Base-X Console
SFP Port Port
2 N/A
Quantity
1
4
2
1
6
1
1
1
1
1
Product Introduction
Power
Fan
Supply
1 x fixed
N/A power supply
module
Remarks
Pre-installed on the
device.
