Installation Guide
(4) Insert the twisted pair cable with RJ45 connector into the corresponding ports according to the panel
identification, and distinguish the crossover cable and the straight-through cable.
3.6

Bundling Cables

3.6.1

Precautions


Bundle the power cords and other cables in a visually pleasing way.

Make sure that the fibers at the connectors have natural bends or bends of large radius.

Do not bind fibers and twisted pair cables too tightly, as this may press hard the fibers and affect their useful
life and transmission performance.
3.6.2

Bundling Steps

(1) Bind the drooping part of the optical cables and twisted pairs, and lead them to both sides of the chassis for
convenience.
(2) On both sides of the chassis, fasten the optical fibers and twisted pair cables to the cable management ring
or cabling chute.
(3) For the power cords, you should bind them closely along the bottom of the chassis, in a straight line wherever
possible.
3.7

Verifying the Installation

Caution
Turn off the power to avoid personal injury and damage to components caused by incorrect connection.

Verify that the ground wire is connected.

Verify that the Ethernet cables and power cords are properly connected.

Verify that the cables with a distance of 100 meters (328.08 feet) are managed indoors. If not, check whether
the power supply and interfaces are protected from lightning strikes.

Verify that there is a minimum clearance of 100 mm (3.94 in.) around the switch.
18
Installing the Switch
