Mini-GBIC and SFP Modules

We provide appropriate SFP modules (Mini-GBIC modules) according to the port types. You can select the
module to suit your specific needs. Besides, the Mini-GBIC-GT modules are also supported. The following
models and technical specifications of some SFP modules are listed for your reference. For details about the
technical specifications, see Ruijie Hybrid Cable Installation and Reference Guide.
Table 6-2 Table B-1 Models and Specifications of 1000M Mini-GBIC (SFP) Optical Modules
Model
MINI-GBIC-SX-MM850
MINI-GBIC-LX-SM1310
GE-eSFP-SX-MM850
GE-eSFP-LX-SM1310
GE-SFP-LX-SM1310
MINI-GBIC-LH40-SM1310
GE-SFP-SX-SM1310-BIDI
GE-SFP-SX-SM1550-BIDI
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
MINI-GBIC-ZX50-SM1550
MINI-GBIC-ZX80-SM1550
MINI-GBIC-ZX100-SM1550
GE-SFP-SX
GE-SFP-LX
SFP-MM850
Waveleng Cable
th (nm) type
850 MMF
1310 SMF
850 MMF
1310 SMF
1310 SMF
1310 SMF
1310 MMF
1550 MMF
1310TX/1
SMF
550RX
1550TX/1
SMF
310RX
1310TX/1
SMF
550RX
1550TX/1
SMF
310RX
1550 SMF
1550 SMF
1550 SMF
850 MMF
1310 SMF
850 MMF
24
Intensity of
Transmitted
DDM
Light (dBm)
(Yes/No)
Min
No -9.5
No -9.5
Yes -9.5
Yes -9.5
No -9.5
Yes -2
No -10
No -10
Yes -9
Yes -9
Yes -5
Yes -5
Yes -5
Yes 0
Yes 0
No -9.5
No -9.5
No -9.5
Intensity of
Received Light
(dBm)
Max Min Max
-3 -17 0
-3 -20 -3
-3 -17 0
-3 -20 -3
-3 -20 -3
3 -22 -3
-5 -17 -3
-5 -17 -3
-3 -20 -3
-3 -20 -3
0 -24 -1
0 -24 -1
0 -22 -3
4.7 -22 -3
5 -30 -9
-3 -17 0
-3 -20 -3
-3 -17 0
