Table 1-2 Front Panel Components
No. Component
System LED
1
2 LED Mode switch
3 Reset button
1000 Mbps
4 Ethernet port
status LED
1000 Mbps
5
Ethernet port
SFP port
6
SFP port status
7
LED
8 Label
Description
Off: The switch is not powered on.
Slow blinking green (flash every two seconds): The switch is operating
properly, but has insufficient power for PoE, or is not connected to
Ruijie Cloud.
Fast blinking green (10 flashes per second): The switch is upgrading or
restarting.
Blinking green (flash twice every 4 seconds, one long and one short): A
loop has occurred, or the switch has insufficient power for PoE.
Solid green: The switch is operating normally, and is connected to
Ruijie Cloud.
LED Mode switch toggled to left (Mode 1): The port LED status
indicates the status of traffic transmission. Solid green means that the
port is connected, but is not sending and receiving data, while blinking
green means that the port is connected, and is sending and receiving
data.
LED Mode switch toggled to right (Mode 2): The port LED status
indicates the PoE status. Solid green means that the port is supplying
power, while blinking green means that the port is in power overload
state.
Press and hold the button for less than 2 seconds to restart the system;
Press and hold the button for more than 5 seconds until the system status
LED starts blinking to restore factory settings and restart the system.
PoE status:
○ Off: PoE is disabled.
○ Solid green: PoE is enabled.
○
Blinking green: PoE overload has occurred.
Port status:
○ Off: No link is established on the port.
○
Solid green: The port is operating at 10 Mbps/100 Mbps/1000 Mbps,
but is not receiving or sending data.
○ Blinking green: The port is operating at 10 Mbps/100 Mbps/1000
Mbps, and is receiving or sending data.
10/100/1000Base-T ports with auto-negotiation, connected to Cat5e cables.
1000M Base-X SFP port, backward compatible with 100Base-FX.
Off: No link is set up on the port.
Solid green: The port is operating at 1000 Mbps, but is not receiving or
sending data.
Blinking green: The port is operating at 1000 Mbps, and is receiving or
sending data.
Located at the bottom of the switch.
