APPENDIX A: BOXILLA DISCOVERY

A.1 BOXILLA DISCOVERY
The Emerald DESKVUE unit can be discovered and managed by the Boxilla
®
DESKVUE firmware version 1.1.0.r94 or later and the Boxilla unit is using firmware version 4.7.0 or later. Older
firmware versions do not support integrating DESKVUE and Boxilla.
NOTE: If the DESKVUE unit is managed by another Boxilla Manager, it will need to be factory reset prior to
performing the Boxilla Discovery process.
A.1.1 DISCOVERING AND MANAGING THE DESKVUE UNIT
To discover and manage the DESKVUE unit through the Boxilla Manager:
1. Verify that the DESKVUE unit is turned on.
2. Verify that the the DESKVUE unit is connected to the network so that Boxilla can detect it.
3. Verify that the IP Address (192.168.1.1) is not in use. Otherwise, the Boxilla discovery process will not work.
4. In the Boxilla administrative interface, go to Discovery and press the "Discovery" button. The DESKVUE unit
should then be discovered and show as Unmanaged under model EMD5004-R, as shown in Figure A-1 below:
78
FIGURE A-1: DETECTED DESKVUE UNIT SHOWING AS UNMANAGED
