CHAPTER 2: APPLICATION DIAGRAM AND SPECIFICATIONS
SPECIFICATION
Dimensions
Weight
Connectors
Maximum Distance from Network
User Interface
Mounting Kits
Power
Input Voltage/Volts
Input Current/Amps
Output Voltage/Volts
Output Current/Amps
Power Consumption/Watts
Heat Dissipation/BTU/h
Operating Temperature
Storage Temperature
Operating Humidity
Maximum Altitude/Feet
Vibration (Maximum)
Shock (Maximum)
Compatibility
TABLE 2-1. PRODUCT SPECIFICATIONS
DESCRIPTION
Unit: 7.17" H x 1.42" W x 7.01" D (182 x 36 x 178 mm)
2.95 lb. (1.34 kg)
(4) DisplayPort™ outputs: (3) 4K and (1) 5K;
(3) USB 3.2 Gen 2x1, Type A (SuperSpeed USB);
(1) USB 3.2 Gen 1x1, Type A (SuperSpeed USB);
(1) USB-C, USB 3.2 Gen 2x2 (SuperSpeed USB);
(1) 3.5mm Analog Audio Output;
(1) 3.5mm Analog Microphone Input;
(2) RJ-45 1Gbps Network Ports;
(1) Power Input
328 feet (100 m) using CATx cabling
Emerald On Screen Display (OSD)
®
VESA mount included
External desktop power supply
100-240VAC, 50/60Hz
1.5 Amps
19.5VDC
4.62 Amps
90 Watts maximum
306.9 BTU/h
50 to 95ºF (10 to 35ºC)
-40 to +149ºF (-40 to +65ºC)
20 to 80% (non-condensing)
Operating: <5,518 ft. (1,681 m);
Storage: <19,234 ft. (5,862 m)
Operating: 0.26 GRMS;
Storage: 1.37 GRMS
Operating: 40 G;
Storage: 105 G
Boxilla managers, Emerald transmitters, and virtual machines (RDP, PCoIP,
H.264/H.265)
