CHAPTER 3: APPLICATION
NOTE: The items shown in the connection list are provided for example only; the list shown on your screen is
dependent upon connections made with your DESKVUE unit or connections configured in Boxilla if the DESKVUE unit
is managed. When DESKVUE is not managed and is in a factory default state, no connections will be shown by default.
Table 3-8 explains the options on the "Connections List" screen.
ITEM
Search connections box
Filter By
Add New
Check Button
36
TABLE 3-8. CONNECTION LIST OPTIONS
DESCRIPTION
Type in this search box to customize the items shown in the connection list. When
you type in this box, all connections containing that search term will be displayed,
as shown in the example in Figure 3-39 below:
FIGURE 3-39: CONNECTION SEARCH BOX RESULTS
Click in the appropriate check box(es) if you want to filter your results by a specific
connection type: transmitter, RDP, PCoIP, or H.264.
Click on this button to manually add a new transmitter, RDP, PCoIP, or H.264 Stream
Connection connection.
Click on the "Check" button to test the connection. When you click on this button, the
system attempts to reach the connection and displays a connection status message,
as shown in Figure 3-40 below:
FIGURE 3-40: CONNECTION STATUS SCREEN
NOTE: When using the "Check" button, press the default hot keys + X to close the
window and return to the Connections tab. If the connection window is closed
using the "x" button in the top right of view, the hot key + X still needs to be used to
return to the Connections tab on the OSD. By default, the hot keys are CTRL, CTRL,
so using CTRL, CTRL, X would break this connection.
