Black Box EMERALD DESKVUE User Manual page 16

CHAPTER 3: APPLICATION
Table 3-2 explains the information and options on the OSD screen.
ITEM
Boxilla Operation Mode
User
16
TABLE 3-2. OSD
DESCRIPTION
In the top left corner of the screen, the system will display "Unmanaged" when the
device is not managed by a Boxilla unit. It will display "Managed" when the device
is managed by a Boxilla unit. An unmanaged unit can only connect to unmanaged
transmitters and both RDP and PCoIP virtual machines, along with H.264 streams.
When the Boxilla Operation Mode is "Managed," you can hover your mouse over
the "Boxilla Operation Mode" text to see the device's IP address, which is shown in
Figure 3-8 below:
FIGURE 3-8: BOXILLA OPERATION MODE WITH IP ADDRESS
NOTE: To connect to managed transmitters that are part of a KVM domain, your
device must be managed by the same Boxilla that manages the other parts of the
KVM domain.
The current version of Boxilla will download a security token so that your device can
communicate with other managed transmitters. When the Emerald
unit is unmanaged, you need to add the connections, workspaces, and users via
the DESKVUE unit. When it is managed, configuration can be done through the
Boxilla manager.
In the top right corner of the screen, the system will show the user that is logged
into the DESKVUE unit. It will also show that user's access level.
The "admin" user can also log out, shut down, or restart the system by clicking
on the drop-down menu symbol to the right of "admin" and then clicking on
the corresponding option from the drop-down menu. The options are shown in
Figure 3-9 below:
FIGURE 3-9: ADDITIONAL ADMIN OPTIONS
