CHAPTER 3: APPLICATION
Table 3-1 explains the options on the Username and Password screen.
FIELD/ITEM
Username
Password
Remember me checkbox
Keyboard type drop-down list box
Log On button
Power button
14
TABLE 3-1. USERNAME AND PASSWORD SCREEN
DESCRIPTION
Enter the username. By default, the username is "admin" (without the quotes). You
can change the username, which is a unique name that uses 1–32 characters. The
username can be any valid username for a Microsoft
the username cannot contain " "/ \ [ ] ; | = + * ? < > `
Enter the password. The password is blank (no password) unless changed or
managed by Boxilla. You can view the password that you entered by clicking on
the View symbol that is located to the right of the password entry area, as shown
in Figure 3-5 below:
The password can contain a minimum of 0 characters (blank) and a maximum of
32 characters. It can be any valid password for a Microsoft operating system. The
user password MAY contain the following special characters , ~ : ! @ # $ % ^ & ' { }
which means the password cannot contain " "/ \ [ ] : ; | = , + * ? < > `'
Click in the check box if you want the system to remember the last username
that you entered. A check mark will appear in the checkbox to indicate that the
credentials will be remembered. If you don't want the system to remember the
last username and password that you entered, leave the check box empty. If a
check mark appears in the box, click on the check box again to remove it.
Click on the drop-down menu symbol in the keyboard selection box and then
select the appropriate keyboard type. The drop-down menu displays available
options, as shown in Figure 3-6 below:
After you enter the username and password, and (optionally) click in the
"Remember me" check box, click on the "Login" button to log into the system.
Click on this button to turn off the system.
1.877.877.2269
FIGURE 3-5: VIEW ICON
FIGURE 3-6: KEYBOARD SELECTION BOX
