CHAPTER 3: APPLICATION

3.5 AUDIO SETTINGS TAB

When the Audio" tab is selected, the administrator can configure the audio output as shown in Figure 3-16 below:
Table 3-5 explains the options on the "Audio Settings" page.
ITEM
Analog
HDMI
Output Card
Output Volume
22
FIGURE 3-16: AUDIO SETTINGS PAGE
TABLE 3-5. AUDIO SETTINGS
DESCRIPTION
Configure the analog audio output by choosing an option from the drop-down list
box. The example in Figure 3-17, below, may differ from the options shown on your
screen.
FIGURE 3-17: ANALOG AUDIO SETTINGS DROP-DOWN BOX
Configure the embedded HDMI audio output.
Configure the output audio channel that will be used.
Configure the volume of the audio output.
