CHAPTER 3: APPLICATION
Table 3-4 explains the options on the "Display Settings" screen.
ITEM
Identify
Detect
Primary Display
Selected Display
Manufacturer Info
Display Orientation
Resolution
Refresh Rate
Connected Interface
Save/Cancel buttons
TABLE 3-4. DISPLAY SETTINGS
DESCRIPTION
The "Identify" function places numerical numbers on each connected display to
show the orientation/order that the system is using. An example is shown in Figure
3-14 below:
FIGURE 3-14: SCREEN NUMBER FROM IDENTIFY FUNCTION
Use the "Detect" button to determine what displays are connected to the DESKVUE
unit. This function is best used when new displays were added or switched around
after the unit has been powered on. There will not be a confirmation message,
Choose the primary display from the option(s) in the drop-down list box.
This is a read-only field that shows which monitor is currently selected, and the settings
below this relate to this monitor only.
This is the name of attached display provided by its EDID table.
Use this option to choose the selected display's orientation to best fit the application.
Choose the desired screen resolution for the selected display from the drop-down list
box. Resolutions that are displayed in the list are provided by the display's EDID table
and can vary depending on the type of display used. The display's preferred resolution
includes an asterisk to the right of the resolution name.
Choose the desired refresh rate for the selected display from the drop-down list box.
Refresh rates are defined by the type of monitor that is used, and the information is
derived from the attached display's EDID table.
This is the label that DESKVUE applies to the display's physical interface. Figure 1-2
identifies the interfaces.
Click on the "Save" button to save information that you entered. Click on the "Cancel"
button to discard information that you entered. The "Save" and "Cancel" buttons are
shown in Figure 3-15 below:
FIGURE 3-15: SAVE AND CANCEL BUTTONS
