CHAPTER 3: APPLICATION
Table 3-7 explains the options on the "Transmitter Settings" page.
ITEM
Transmitter IP Address
Transmitter Information
26
TABLE 3-7. TRANSMITTER SETTINGS
DESCRIPTION
If the IP address is known for the transmitter that needs accessed/configured, enter it
into this field and then press the "Apply" button to establish an initial connection. Once
the connection is established, the remaining buttons on the page will be activated. If
the IP address of the transmitter is not known, use the "Discover" button to detect it.
Figure 3-21 below shows the transmitter settings field.
.
FIGURE 3-21: TRANSMITTER IP ADDRESS SETTING
This page will display the transmitter's MPN (Manufacturing Part Number), serial
number, MAC Address, and firmware version. An example is shown in Figure 3-22
below:
FIGURE 3-22: TRANSMITTER INFORMATION SCREEN
