Black Box EMERALD DESKVUE User Manual page 27

CHAPTER 3: APPLICATION
ITEM
Transmitter Upgrade
Restore
TABLE 3-7. TRANSMITTER SETTINGS (CONTINUED)
DESCRIPTION
Use this option to update the DESVKUE unit's firmware. Place the firmware file on a
FAT- or FAT32-formatted flash drive, and then select the file to process the upgrade.
An example containing a firmware file is shown in Figure 3-23 below:
Use this option to perform a factory reset to restore the transmitter back to its
default state. The default IP for transmitters is 192.168.1.22. You will need to confirm
the action by clicking on the "YES" button or cancel the action by clicking on the
"NO" button, as shown in Figure 3-24 below:
1.877.877.2269
FIGURE 3-23: TRANSMITTER UPGRADE SCREEN
FIGURE 3-24: TRANSMITTER RESTORE SCREEN
